Ultra-Low Temperature Freezer

Medical Cryogenic Transport Equipment

The Cryo S series, the most advanced refrigeration solution in the industry. The Cryo S 100 Stirling refrigerator serves as the core cooling source, offering ultra-low temperatures and fast cooling capabilities. With a maintenance-free lifespan of over 50,000 hours, it withstands bumps and shakes with ease. Specifically designed for medical scenarios, the ultra-low temperature mobile safe provides reliable storage and transportation.

The machine is equipped with a built-in large-capacity lithium battery, eliminating the need for an external power source during vaccine transportation. Additionally, the NFC/RF ID electronic lock, in connection with IoT technology, ensures the safety of transported goods. The IoT system enables real-time tracking and tracing of the machine, access to operating data, remote control functionality, and data export, providing users with full control and traceability.

CPF001L86:

Compact and lightweight, this model can reach temperatures as low as -86°C, making it ideal for transporting biological samples such as vaccines, bacterial viruses, blood, human organs, and immune medical products that require extremely low temperatures.

CPF015L80 / CPF130L80:

These models offer both heating and cooling capabilities, providing flexibility for full-temperature transportation. They are suitable for transporting high-end food materials, medicine, vaccines, flowers, hot food, frozen seafood, and more.

Experience the reliability and versatility of the Cryo S series for your refrigeration needs.

Model
CPF001L86
CPF015L80
CPF130L80
Product Name
Ultra-low Transportable Cryogenic Freezer
Portable Cryogenic Freezer
Stirling Mobile Freezer
Product Photo
Outside Dimensions
L293 x W306 x H452mm
L620 x W493 x H625 mm
L790 x W910 x H1265 mm
Internal Dimensions
L150 x W134 x H56mm
L237 x W296.5 xH 239 mm
L470 x W547 x H500 mm
Volume
1L
15L
130L
Weight
13.5KG
36KG
120KG
Supply Voltage
DC 12 - 30V
DC 12 - 30V
DC 18 - 30V
Power consumption
100W
80W
400W
Temperature Control Range
-86°C to 4°C
-80°C to 30°C
-80°C to 30°C
Temperature Control Accuracy
±2°C
±3°C
±3°C
Battery Capacity
1H
1H / 4H
1H / 4H
Electronic Lock
NFC / RFID
NFC / RFID
NFC
Logistic1

Food cold chain solutions



Portable ultra-low temperature Freezer  uses  the  most advanced Stirling  technology.  No need to afraid of  bumps and  shaking during  transportation, it can achieve a deep low  temperature of -40°C. The heating wire provided with the machine gives the  heating function  of  30°C. Wide temperature zone can meet different  cargo  transportation  requirements.  Suitable   for  transportation   of high- end goods such as medicines,ingredients such as medical, flowers, central kitchens, hot food, seafood, etc. Use  the  car cigarette lighter to drive the machine to work normally in vehicle. With built-in large -capacity lithium battery it can work without external power for more than 1 hour. NFC electronic lock in connection with the loT to  ensure  the  safety  of  transported  goods. The  loT supports  real-time track and trace of machine and operating data, remote control of the machine and export of data, enable user to to achieve full control and traceability.

Model
CPF025L40
CPF370L20
CPF190L30
Product Name
Portable ultra-low temperature incubator
Stirling Mobile Refrigerator
Stirling Mobile Refrigerator
Product Photo
Outside Dimensions
L620 * W493 * H625 mm
L790 x W910 x 1707mm
L790 * W910 * H1265 mm
Internal Dimensions
L237 * W 296.5 * H374mm
L563 x W660 x H1110 mm
L563 * W660 * H600 mm
Volume
25L
370L
190L
Weight
36KG
102KG
78KG
Supply Voltage
DC 12 - 30V
DC18 - 30V
DC18 - 30V
Power consumption
80W
170W
170W
Temperature Control Range
-40°C to 30°C
-20°C to 30°C
-30°C to 30°C
Temperature Control Accuracy
±0.1°C
±0.1°C
±0.1°C
Battery Capacity
1H / 4H
1H / 4H
1H / 4H
Electronic Lock

Portable Ultra-Low Temperature Incubator

Use Cryo S50/Cryo S100 Stirling machine as the refrigeration core, integrated air duct, full temperature operation, ultra-low power consumption, ultra-low noise, precise temperature control (core cold source accuracy can be as low as 0.1 °C, complete 360-degree anti-shake in all directions.

According to different leather products, we can provide you with different types of cooling cycle configurations; built-in radiators and heaters; optimal cooling systems, main cooling systems and optional heating systems.

The  loT supports  real-time track and trace of machine and operating data, remote control of the machine and export of data, enable user to to achieve full control and traceability.

Model
CPFXL30
CPFXL30I
Product Name
Product Photo
Outside Dimensions
L487 * W314 * H290 mm
L427 x W161 x H155mm
Internal Dimensions
Volume
Weight
8.7KG
4.4KG
Supply Voltage
DC12-36V AC220V
DC12-36V AC220V
Power consumption
80W
80W
Temperature Control Range
-50°C to 10°C
-50°C to 10°C
Temperature Control Accuracy
±0.1°C
±0.1°C
Battery Capacity
-
-
Electronic Lock
-
-
Logistic 3
Logistic 2
